Cloudray EC Series Neo 30W 60W CO2 Laser Marking Engraver

SKU: CM54CR30AJPA-USA
40
People are viewing this right now
Regular price $ 4,299.00 USD Sale price $ 2,799.00 USD
Power: 30W
Shipping Destination: United States
Plug: American Plug
Add to Compare
Shipping calculated at checkout.
Dedicated Customer Support: US & EU Based Tech.
Laser Machine: 2-Year Warranty.
Laser engravers with FDA, CE, ROHS certifications, and QC quality inspection report.

Safe & secure

Frequently Bought Together

Cloudray EC-30 30W CO2 RF metal tube laser marking engraver for non-metal materials
Cloudray CO2 F-Theta Lens
Cloudray Partner LightBurn Software For Laser Cutter Control / Galvo Laser Control
D69 D80 D100 A Series Rotary Attachment Set
Cloudray Laser Machine Protective Cover For CO2 Galvo Laser & UV Laser
Cloudray 135W FE-200M Mini Smoke Purifier Fume Extraction System
Advantages of Cloudray adjustable honeycomb table
This item: Cloudray EC Series Neo 30W 60W CO2 Laser Marking Engraver
Regular price $ 4,299.00 USD Sale price $ 2,799.00 USD
Cloudray CO2 F-Theta Lens
Sale price $ 219.00 USD
Cloudray Partner LightBurn Software For Laser Cutter Control / Galvo Laser Control
Sale price $ 199.00 USD
Cloudray D80 D100 A Series Rotary Attachment Set
Sale price $ 199.00 USD
Cloudray Laser Machine Protective Cover For CO2 Galvo Laser & UV Laser Sale price $ 399.00 USD
Cloudray 135W FE-200M Mini Smoke Purifier Fume Extraction System
Sale price $ 699.00 USD
Cloudray Adjustable Honeycomb Table for Laser Engraver & Cutter
Sale price $ 29.00 USD
Cloudray EC-30 30W CO2 RF metal tube laser marking engraver for non-metal materials

Cloudray EC Series Neo 30W 60W CO2 Laser Marking Engraver

Cloudray EC Series 30W 60W high-speed precision CO2 laser engraver for hobbyists and small businesses
Cloudray EC Series CO2 laser engraver features for non-metal engraving, 10mm cutting depth and 0.01mm precision
RF metal laser tube compared with glass laser tube and diode laser for CO2 laser engraving speed and accuracy
Cloudray EC-30 vs EC-60 CO2 laser engraver comparison for design type, beam expander and work area
Cloudray RF metal tube CO2 laser engraver 10000mm per second marking speed comparison
Cloudray EC Series CO2 laser engraver 0.01mm line width for fine detail engraving
Cloudray EC-30 cuts up to 6mm wood and EC-60 cuts up to 10mm wood
Cloudray EC Series CO2 laser engraver extended slide expands work area for batch processing
Cloudray customized laser controller with camera preview, LightBurn support and optional marking functions
Cloudray CO2 laser engraver for wood, paper, cardboard, acrylic, rubber, glass, stone, leather, fabric and coated metals
Cloudray CO2 laser marking applications for tumblers, mugs, glass, acrylic, wood, leather, clothing and cardboard labels
Cloudray CO2 laser engraver used in packaging, apparel, automotive, education, healthcare, signage, furniture and crafts
Cloudray EC-30 CO2 laser engraver basic package includes machine, USB drive, foot switch, safety glasses, tools and QS reports

Model EC-30 EC-60
Laser Power 30W (Up to 38W) 60W
Wavelength 10,600 nm
Working Area 210 × 210 mm 300 × 300 mm
Laser Frequency 0–25 kHz
Max. Cutting Depth 6 mm 10 mm
Max. Engraving Speed 10,000 mm/s 3,000 mm/s
Positioning Accuracy ±0.1 μm
Software LightBurn Compatible
Compatible Operating Systems Windows XP, Vista, 7, 8, 10, 11 / macOS
Supported Files PLT, DXF, AI, DST, SVG, GBR, NC, JPC, BOT, BMP, JPG, JPEG, GIF, TGA, PNG, TIF, TIFF, Code39, EAN, PDF417, Data Matrix, QR, etc.
Estimated Laser Service Life 20,000 hrs
Warranty 2 Years for Machine (1 Year for Laser)
Package Weight 48 kg 58 kg
Package Size 97 × 56 × 56 cm 97 × 55 × 48 cm
Ambient Conditions Operating Temperature: 5–35°C
Relative Humidity: Max. 90%
Non-condensing
Power Requirements AC 220 V / 50 Hz or AC 110 V / 60 Hz
According to local power supply
Power Consumption Max. 600 W Max. 750 W
Equipment Protection IP54 (Marking Head), IP20 (Laser Unit)

EC Series Neo User Guide
User Manual
Download
USB Drive Files
Software & Tutorials Included
Download
EC-30 QC Report
Quality Report
Download
EC-60 QC Report
Quality Report
Download
FDA Certificate
Certification
Download
CE Certificate
Certification
Download
EC Series Packing List
Packing List
Download

FAQs
QS Series: Smart Budget Option for Entry-Level Marking & Engraving. Up to 1mm engraving Depth.
MP Series: Professional-Grade Option. Enhanced Marking /Cutting Depth: Up to 5mm
GM Series: Advanced Performance for Industrial Use. 2.5D Deep Engraving +Precise Metal Cutting
UV Series: All-Material & Material-Friendly Engrvers. 3D Inner & Surface Engraving
EC Series: CO2 Precision Engraver for Non-metal Marking & Cutting
Please email us (info@cloudray.com) directly to offer us your working materials, along with the expected effect on those materials by machine, accompanied by pictures or videos.
Galvo systems are fast for fine engraving/shallow cuts.
Gantry systems are better for large-format, thick material contour cutting
EC-30: All-in-one, 500 mm column, 210×210 mm area, 4× beam expander, spot ~0.0645 mm, cuts 6 mm basswood, compact, daily marking & medium materials.
EC-60: Split system, 800 mm column, 300×300 mm area, 8× beam expander, spot ~0.0325 mm, cuts 10 mm basswood, finer spot, deep cutting, large-area & high-precision thick materials.
Yes. The rear panel includes a dedicated “Rotary Attachment” port, confirming compatibility with a rotary attachment.
The maximum marking speed of Cloudray galvanometer system is 15,000 mm/s.
Cloudray recommends a common marking speed range of 2,000 to 5,000 mm/s, which enables high-quality marking for 1mm characters.
Typically, the maximum marking speed can reach the highest positioning speed of the galvanometer, depending on the engraver's specifications.
The machine has 2 years guarantee. If it breaks down, generally speaking, our technician will figure out what the problem may be, according to clients’ feedback. Parts except for consumable parts will be replaced for free if the problems are caused by quality faults. Even if the machine is beyond the warranty, we can still offer technical assistance as your order is placed on www.cloudraylaser.com.
